spec |
PFG-2550H
PFG-2550AH
|
PFG-CS3060AH
PFG-CL3060AH |
PFG-D4080AH |
PFG-50150AHR
PFG-60150AHR
PFG-70150AHR |
Workbench dimension(mm) |
250x500(10"x20")
|
300x600 (12”×24”) |
400x800(16"x32") |
500x1550 (20”×61”)
600x1550 (24”×61”)
700x1550 (28”×61”) |
Max. workbench travel(mm) |
270x550(10.75"x22")
|
340x700 (13”×27”) |
450x860(18"x34") |
560x1650 (22”×65”)
660x1650 (26”×65”)
760x1650 (30”×65”) |
Max. grinding dimension(mm) |
250x500(10"x20")
|
300x600 (12”×24”) |
400x800(16"x32") |
500x1550 (20”×61”)
600x1550 (24”×61”)
700x1550 (28”×61”)
|
Distance from workbench to main shaft center |
500mm(20") |
500mm(20”)
[Option-600 mm(24")] |
550mm(22") |
760mm(30”) |
Grinding wheel speed
60Hz/50Hz |
3500R.P.M(60Hz)
/2900R.P.M(50Hz) |
1750R.P.M(60Hz)/1450R.P.M(50Hz) |
Grinding size |
180x13x31.75mm
(max.200x20x31.75)
(7"x0.5"x1.25")
(max.8"x0.75"x1.25") |
S:180×13×31.75mm
(7"x0.5"x1.25")
L:355x38x127mm
(14"x1.5"x5") |
406x50x127mm
(16"x2"x5") |
405x50x127mm
(16"x2"x5") |
Main shaft motor |
2HP |
2HP(sseries)-5hHP(Lseries) |
5HP |
10HP |
Cooling pump |
1/8HP(Option) |
1/8HP (Option) |
1/8HP |
1/8HP |
Machine operating space mm |
2450x1450(96"x57") |
2600×1800
(102”×68”)
|
3450x2000(136"x79") |
5150x2400×2700
(203”×94”x106")
|
