spec |
M50CA |
M60CA |
M90CA |
M120CA |
Work tank capacity |
850×500×350mm |
1000×600×350mm |
1400×950×520mm |
2200×1200×800mm |
Workbench dimension |
600×360mm |
600×400mm |
1000×600mm |
1600×800mm |
X-axis travel |
300mm |
400mm |
600mm |
1000mm |
Y-axis travel |
250mm |
300mm |
400mm |
500mm |
Z-axis travel |
300mm |
300mm |
400mm |
500mm |
Max. distance between main shaft and workbench |
450mm |
500mm |
700mm |
1000mm |
Discharge energy |
45A |
60 A |
90 A |
120 A |
Quickest processing speed mm3/min
|
400 |
500 |
750 |
1000 |
Finest surface coarseness |
Ra 0.16μm |
Ra 0.1μm |
Ra 0.1μm |
Ra 0.1μm |
Lowest electrode consumption rate |
＜0.1％ |
＜0.1％ |
＜0.1％ |
＜0.1％ |
Max. electrode burden |
50kgs |
60kgs |
200kgs |
500kgs |
Max. workbench burden |
500kgs |
2000kgs |
4000kgs |
8000kgs |
Filter tank capacity |
300L |
400L |
800L |
3000L |
Occupancy (L, W) mm |
1600×1700mm |
2170×2000mm |
5000×3000mm |
5500×4000mm |
Gross weight |
1600kgs |
2300kgs |
5560kgs |
8500kgs |
|
 |
 |
 |
 |
|
